配置

技術規格

數量

目鏡

大視野 PLAN 10X (視場數25mm） FN25

2pcs

平場無限遠消色差明暗場物鏡

PLAN lnflnity 5X BD NA 0.1, WD 16.6

PLAN lnflnity 10X BD NA 0.25, WD 16.0

PLAN lnflnity 20X BD NA 0.40, WD 10.5

PLAN lnflnity 50X BD NA 0.55, WD 5.1

PLAN lnflnity 100X BD NA 0.80, WD 3.01

1pcs

1pcs

1pcs

1pcs

1pcs

C--Mount

1X

1pcs

三目鏡筒

Trinocular tube and C-mount

Interpupillary distance 55mm-75mm 0.7x或1X C-mount

U-CTR30-2 Trinocular tube, FN25, fixed light pass, Bi/Photo: 50/50 100/0 0/100

1pcs

調焦機構

Foucus system

粗微動同軸調焦，微動格值：1~4微米可變，帶鎖緊和限位,最大行程30mm，可放置試樣高度40mm

Coaxial coarse/fine focus system,with tension adjustable and limit stopper.

minimum division of fine focusing 1~4mm，Maximum stroke 30mm, the specimen height 40mm

1pcs

顯微鏡鏡體

Microscope system

10w 高效率白色LED 色溫溫和 包含轉換器 濾色片 明暗場切換裝置 可調視場光闌

Microscope frame with quintuplerevolving nosepiece,

mechanicalstage（right handle）, 10w led illuminator, filter 32.5C-2.

Corresponded to WEEE regulation，Switching device for dark field Adjustable field aperture

1pcs

轉換器

Nosepiece

五孔 轉換器

Nosepiece 5 hole

1pcs

左右手操作可切換，高低位可調工作臺

The left and right hand operation

can be switched, high and low

X 行程 77mm Y 行程 55mm

adjustable stage

X trip 77mm Y trip 55mm

1pcs

落射照明系統

Epi-illumination system

10w LED照明，內置偏移式視場光闌，孔徑光闌，推拉式檢偏器與起偏器

10w led illuminator,Built-in offset field aperture, aperture aperture，

push-pull type detector, and bias

1pcs

聚光鏡

Brightfield condenser

阿貝聚光鏡NA0.9 上下可升降 可調孔徑光闌

Brightfield condenser, N.A. 0.9, Up and down adjustable Adjustable aperture

1pcs

濾色片

Filter

Blue Green and yellow frosted glass

3pcs

電源 Power

100v~240v輸入 100 v to 240 v input AC

1pcs
